Kawasaki MULE PRO-DXT DIESEL

$28,704.00

Contact Trio for:

  • Confirming this product suits your needs
  • Pricing on options and add-ons
  • Current stock availability
  • Delivery or pickup arrangements

MULE PRO-DXT side x sides put down the hardworking muscle of a diesel engine with the versatility of 3- to 6-passenger seating. Featuring a Trans Cab system, this high-capacity vehicle has the ability to move materials and people at the jobsite.

Key Features

  • 3- to 6-passenger Trans Cab System
  • 993
  • 1-ton (907 kg) towing capacity
  • Independent front and rear suspension
  • Kawasaki strong 3-year limited warranty
  • Durable steel-based cargo bed
  • Continuously Variable Transmission (CVT)
  • Electrically selectable 2WD/4WD, dual-mode rear differential
  • Speed-sensitive Electric Power Steering (EPS)
Maximum Power18 kW {24 PS} / 3,600 rpm
Maximum Torque52 Nm {5.3 kgfm} / 2,400 rpm
Engine4-stroke In-Line 3-cylinder diesel
Displacement993 cc
Bore x Stroke74.0 x 77.0 mm
Compression Ratio23.5:1
Valve SystemOHV
Fuel SystemIn-line injection pump
StartingElectric
CoolingLiquid-cooled
LubricationForced lubrication, wet sump
TransmissionDual range (high/low) CVT with reverse
Primary Reduction Ratio3.334 ~ 0.756 (belt converter)
Gear Ratio: Forward (High)1.952 (34/33 x 36/19)
Gear Ratio: Forward (Low)3.876 (45/22 x 36/19)
Gear Ratio: Reverse3.009 (27/17 x 36/19)
Final Reduction Ratio: Front6.382 (31/17 x 35/10)
Final Reduction Ratio: Rear6.245 (31/21 x 55/13)
Final Drive2WD/4WD, shaft, dual-mode differential
FrameLadder type, tubular steel
Front SuspensionDouble wishbone
Rear SuspensionDouble wishbone
Front Wheel Travel222 mm
Rear Wheel Travel217 mm (left), 220 mm (right)
SteeringRack and pinion with Electric Power Steering
Rake4.4°
Steering Angle (L/R)40° (IN) / 31° (OUT), 40° (IN) / 31° (OUT)
Front Tyres26 x 9.00-12 4PR
Rear Tyres26 x 11.00-12 4PR
Front BrakesDual ø212 mm discs
Front CalipersTwo-piston
Rear Brake/sDual ø212 mm discs
Rear Caliper/sSingle-piston
Parking BrakeDual discs (mechanical)
Dimensions (LxWxH)3,385 x 1,625 x 1,970 mm
Wheelbase2,345 mm
Road Clearance260 mm
Seat Height880 mm (front), 965 mm (rear)
Curb Weight*900 kg
Estimated Dry Weight**861 kg
Fuel Capacity30 litres
Tread Front / Rear1,389 mm / 1,321 mm
Turning Radius4.8 m
Cargo Bed Dimensions (LxWxH): 6-Person Mode560 x 1,363 x 279 mm
Cargo Bed Dimensions (LxWxH): 3-Person Mode1,085 x 1,363 x 279 mm
Cargo Bed Capacity: 6-Person Mode158 kg
Cargo Bed Capacity: 3-Person Mode453 kg
Seating Capacity3 or 6
Vehicle Load Capacity695 kg
Towing Capacity907 kg
Lighting2x halogen headlights
Model CodeKDT1000BTFNN
