Kawasaki Ninja H2R

Contact Trio for:

  • Confirming this product suits your needs
  • Pricing on options and add-ons
  • Current stock availability
  • Delivery or pickup arrangements

The development of the Ninja H2R motorcycle goes beyond the boundaries of any other Kawasaki motorcycle. Born of unprecedented inter-company collaboration within the Kawasaki Heavy Industries, Ltd. (KHI) Group, the world's only limited production supercharged hypersport model represents the pinnacle of Kawasaki engineering, delivering astonishing acceleration and mind-bending top speed suitable only for closed courses.

Key Features

  • 998
  • Lightweight trellis frame
  • Fully adjustable high-performance racing suspension
  • Advanced electronics
  • Closed-course only hypersport
  • Carbon-fibre aerodynamic devices
  • Bosch IMU with Kawasaki's
Maximum Power228.0 kW {310 PS} / 14,000 rpm
Maximum Power with Ram Air240.0 kW {326 PS} / 14,000 rpm
Maximum Torque165.0 Nm {16.8 kgfm} / 12,500 rpm
Engine4-stroke In-Line Four
Displacement998 cc
Bore x Stroke76.0 x 55.0 mm
Compression Ratio8.3:1
Valve SystemDOHC, 16 valves
Fuel SystemFuel injection: ø50 mm x 4 with dual injection
Intake SystemKawasaki Supercharger
IgnitionDigital
StartingElectric
CoolingLiquid-cooled
LubricationForced lubrication, wet sump with oil cooler
Transmission6-speed, return, dog-ring
Primary Reduction Ratio1.551 (76/49)
Gear Ratio: 1st3.188 (51/16)
Gear Ratio: 2nd2.526 (48/19)
Gear Ratio: 3rd2.045 (45/22)
Gear Ratio: 4th1.727 (38/22)
Gear Ratio: 5th1.524 (32/21)
Gear Ratio: 6th1.348 (31/23)
Final Reduction Ratio2.333 (42/18)
ClutchWet multi-disc, manual
Final DriveChain
FrameTrellis, high-tensile steel, with Swingarm Mounting Plate
Front Suspensionø43 mm inverted fork with rebound and compression damping, spring preload adjustability and top-out springs
Rear SuspensionNew Uni Trak, Öhlins TTX36 gas-charged shock with piggyback reservoir, compression and rebound damping and spring preload adjustability, and top-out spring
Front Wheel Travel120 mm
Rear Wheel Travel135 mm
Rake25.1°
Trail108 mm
Steering Angle (L/R)27° / 27°
Front Tyre120/600 R17
Rear Tyre190/650 R17
Front Brake/sDual semi-floating ø330 mm Brembo discs
Front Caliper/sDual radial-mount, Brembo Stylema monobloc, opposed 4-piston
Rear Brakeø250 mm disc
Rear CaliperBrembo, opposed 2-piston
Dimensions (LxWxH)2,070 x 850 x 1,160 mm
Wheelbase1,450 mm
Road Clearance130 mm
Seat Height830 mm
Curb Weight*216 kg
Fuel Capacity17 litres
Model CodeZX1000YRFNN
